PCCOOLER CPS YS850 Power Supply, 850W 80 Plus Gold Certified Fully Modular PCIe 5.1 & ATX 3.1 Gaming PSU, Wide Compatibility, 135mm FDB Fan, Full Japan Electrolytic Capacitors
Share
Email
Facebook
Twitter
Specifications
- Mfr Part Number: YS850
- Features:
- Brand New ATX 3.1 Certification | Supporting PCI-e 5.1 Specification
- Up to 90% Conversion Efficiency | 80 PLUS Gold Certification
- 100V-240V Global Wide Voltage Range
- Full Japanese Electrolytic Capacitors
- Hybrid Mode Fan | CYBENETICS A Silent Certification
- Full Modular PVC Embossed Cable160x150x86mm
- Type: ATX3.1
- Color: Black
- Output Power: 850W
- Certification: 80PLUS GOLD/Cybenetics GOLD
- Topology: Active PFC+Full Bridge SRCLLC+DC to DC
- AC Input Voltage: 100-240VAC
- Protection: OVP/UVP/OCP/SCP/OTP/OPP/SPD
- Hold Up Time: >=18ms(90% Load)
- Safety: CB/CE/EAC/UKCA/CCC/FCC/TUV/cTUVus/CAN ICES-003(B)/NMB-003(B)
- Environmental Compliance: Rohs, WEEE, EAEU, ERP2014
- Fan: FDB (Fluid Dynamic Bearing)
- Fan Size: 135mm
- Fan Work Mode: Hybrid Mode
- Capacitors: All Japanese electrolytic capacitors
- Operating Temperature: 0-50C
- MTBF: 100,000 Hours
- Modularity: Full Modular
- Cable Type: PVC Embossed Cable
- Output Wire:
- Main Power Connector(20+4)Pinx1: 1x610mm
- CPU(4+4)Pinx1: 2x700mm
- PCI-E(6+2)Pinx1: 3x750mm
- SATAx4: 2x500+150+150+150mm
- SATAx2: 2x400+150mm
- 4Pin Peripheralx3: 1x450+120+120mm
- 12V-2x6 (600W)x1: 1x700mm
- Physical Dimension(LxWxH): 160x150x86mm
- *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country. All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.
