Specifications

• Mfr Part Number:T9-423
• Feature:
  • Designed for High Performance Requirements
  • Excellent Performance
  • The Ideal Choice for SMB Data Management
  • Higher Transmission Speed
  • High Speed Network and Flexible Extension
  • Small-sized Compact Design
  • Very Quiet
  • Flexible Configuration and Management of Disk Arrays
  • Across-Platform File Management and Sharing
  • Enhance the Safety of your Data with a Superior File System
  • Virtualization Storage Solutions
  • Multiple Backup Solutions
  • Striving to Satisfy Small and Medium-sized Businesses
• Processor:
  • Processor Model:Intel Celeron N5105/N5095
  • Processor Architecture: X.86 64-bit
  • Processor Frequency: Quad Core 2.0 GHz (Max burst up to 2.9 GHz)
  • Hardware Encryption Engine: Yes
  • Hardware Transcoding Engine: H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60
• Memory:
  • System Memory:8GB
  • Pre-installed Memory module: 1
  • Total Memory Slot Number: 2 (SO-DIMM)
  • Maximum Supported Memory: 32 GB (16 GB + 16 GB)
  • Note: TerraMaster reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance
• Storage:
  • Disk Slot Number:9
  • Compatible Drive types:3.5" SATA HDD,2.5" SATA HDD,2.5" SATA SSD
  • Maximum Internal Raw Storage Capacity:180TB (20TB x 9) (Capacity may vary by RAID types)
  • Max Single Volume:108TB
  • Drive Hot Swap:Yes
  • Note:
    - Hard drive vendors will release their latest models of hard drives, and Maximum internal raw storage capacity may be adjusted accordingly
    - The maximum single volume size is not directly related to the maximum raw capacity
• File System:
  • Internal Drive:EXT4, BTRFS
  • External Drive:EXT3, EXT4, NTFS, FAT32, HFS+
• External Ports:
  • 2 x RJ-45 2.5GbE Network Jack
  • 2 x Type-A USB 3.1 Gen2 Port
  • 1 x HDMI
  • 1 (PCIe3.0 x2) xM.2 2280 NVMe Slot
• System Fan:80 mm x 80 mm x25mm 3 pcs
• Fan Mode:Smart, High speed, Middle speed, Low speed
• Noise Level:31.2dB(A) (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in idle state)
• Power Supply:250W
• AC Input Voltage:100V - 240V AC
• Current Frequency:50/60 Hz, single frequency
• Power Consumption:
  • 72W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state)
  • 29W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation)
• Limited warranty:2 years
• Certificate:FCC, CE, CCC, KC
• Environment:RoHS, WEEE
• Temperature:
  • Working Temperature:0 C ~ 40 C (32 F ~ 104 F)
  • Storage Temperature:-20 C ~ 60 C (-5 F ~ 140 F)
  • Relative Humidity:5% ~ 95% RH
• Size: 334 x 135 x 295 mm
• Packaging Size: 467 x 225 x 390 mm
• Weight:
  • Net Weight: 6.9 Kg
  • Gross Weight:8.9Kg
• Package Contents:
  • Host unit (x1)
  • Power cord (x1)
  • RJ-45 network cable (x1)
  • Quick Installation Guide (x1)
  • Limited Warranty Note(x1)
  • Screws(a few)
