ADESSO NUSCAN 1600U 1D Handheld CCD Barcode Scanner (USB)
Share
Email
Facebook
Twitter
specification
- Mfr Part Number: NUSCAN 1600U
- Features:
- Reliable Data Collection: the built-in decoder can read the majority of common 1D barcodes and its driver-less operation makes it easy to use with both Windows and Mac operating systems
- Ergonomic Design: Easy-to-hold grip and a thumb switch offer maximum comfort for long-term scanning
- Superior Scanning Performance: The 300 scans per second scan rate and innovative high pixels CCD engine offers fast and accurate scanning results
- Drop Protection: The drop-protection design prevents damage due to accidental drops of less than 1.5 meters
- Long Scanning Range: The scanner is able to scan barcodes up to a distance of 12 inches
- Electrical:
- Power Input voltage: 5VDC +- 5%
- Working Current: 75mA
- Light Source: 675nm visible red LED
- Performance:
- Interface: USB
- Sensor: Linear CCD Sensor
- Minimum Bar Width (1D): 4 mil/0.127 mm PCS 90%, Code 39
- Depth of Field: 0-12 inches (20mil EAN-13, PC 100%)
- Scan Rate: 300 scans/sec
- Scan Angle: Roll: +-30, Pitch: +-60, Skew: +-60
- Print Contrast: 25% EAN13 10 mil
- Alert Operation: Blue LED light indicator and beeper
- Environmental:
- Operating Temperature: -20C to 50C (-4F to 122F)
- Storage Temperature: -40C to 70C (-40F to 158F)
- Operating Humidity: 20% ~ 95% (non-condensing)
- Storage Humidity: 5% to 95% (non-condensing)
- Shock Resistance: Withstanding 1.5m freefall drops
- Regulatory: FCC, CE, RoHS
- Country of Origin: Made in Taiwan
- Supported Symbologies: EAN-8, EAN-13, EAN-13 2 add-on, EAN-13 5 add-on, ISSN, ISBN, UPC-A, UPC-E, Code 11, Code 2 of 5, Code 39, Code 93, Code 128, Codabar, Industrial 2 of 5 , Interleaved 2 of 5, Matrix 2 of 5, Code 39 Full ASCII, Standard 2 of 5
- System Requirements:
- Windows 10, 8, 7, Vista, XP, 2000
- Mac OS X and above
- Interface: USB port
- Includes:
- Adesso NuScan 1600U Handheld CCD Barcode Scanner
- Quick Start Guide
- Mechanical:
- Dimensions (L x W x H): 6.85 x 2.81 x 3.62 inch (174 x 71.5 x 92mm)
- Weight: 0.4 lbs (190 g)
- Cable Length: 6 (1.8meters)
