ICYDOCK ToughArmor MB873MP-B V2 8 Bay M.2 NVMe SSD PCIe 4.0 Mobile Rack Enclosure for External 5.25 inch Drive Bay (8 x OCuLink SFF-8612)
Share
Email
Facebook
Twitter
Specifications
- Mfr Part Number: MB873MP-B V2
- Features:
- Supports 8 x PCIe M.2 NVMe SSDs of all lengths - 30mm (2230), 42mm (2242), 60mm (2260), 80mm (2280), and 110mm (22110)
- Installs into 1 x standard external 5.25 inch optical drive bay
- Uses 8 x OCuLink (SFF-8612) to connect, pin-out defined by SFF-9402 Rev 1.1
- Supports PCIe 4.0 specifications with transfer rates up to 64Gbps per drive bay
- Powers 8 x M.2 SSDs through 2 x 15 - pin SATA power connectors
- Rugged, full-metal enclosure meets flammability requirements
- Equipped with high-performance dual 40 x 20mm cooling fans
- Removable drive tray with tool-less drive installation for easy drive maintenance
- Huge heatsink trays with thermal pads included dispersing heat from the drive
- Anti-Vibration Technology - Creates a safe environment for SSDs
- Active Power Technology - Saves power by shutting off the enclosure when no drive is installed
- EMI Grounding protects SSDs from electrical damage
- Drive ID plugs are included to keep track of your drives
- Eagle-hook tray latch securely holds the drive tray inside the enclosure
- Supports SATA 15-pin and OCuLink cables with locking latch design for a secure connection
- 2 x SATA 15pin power cables are included
- Industry-leading 5 years limited warranty with exceptional customer support
- Color: Black
- Support Drive Size: 8 x M.2 SSD (2230-22110)
- Compatible Drive Type: NVMe
- Number of Drives: 8
- Max Drive Height: M.2 SSD (2230-22110)
- Drive Bay: 1 x 5.25 inch half height bay
- Host Interface: 8 x OCuLink SFF-8612 4i, pin-out defined by SFF-9402 Rev 1.1 (Tri-mode HBA/RAID card compatible)
- Power Input: 2 x 15pin SATA power connector
- Transfer Rate: Up to 64Gbps (depending on SSD speed)
- Support SSD Capacity: No limitation
- Drive Cooling: 2 x 40x40x20mm fan
- Structure / Material: Full metal
- Drive Activity LED Indication: Drive power: solid green; Drive access: flashing green
- Package Contents: Device, user manual, drive ID plugs, screws, 2 x SATA 15pin power cable
- SATA Connector Insertion Rate: 5,000
- Humidity: 5%~65% RH
- Operating Temperature: 0C to 60C (32F to 140F)
- Storage Temperature: -35C to 70C (-31F to 158F)
- Compliance: CE, RoHS, REACH
- Dimension (L x W x H): 146 x 41.3 x 168.6mm
- Product Net Weight: 1136g
- Package Gross Weight: 1147g
- Warranty: 5 years limited warranty
