BDCOM S2900-48P6X 48 Port Gigabit PoE and 6 Port 10G/GE SFP+ Managed PoE Switch

In Stock

This quantity exceeds the amount left in stock.

minus-image minus-image-disabled plus-image plus-image-disabled

Specifications

  • Mfr Part Number: S2900-48P6X
  • 48-Port Gigabit PoE+
  • 6-Port 10G/GE SFP+
  • 370W AC PoE Power Budget
  • 740W DC PoE Power Budget
  • Gigabit PoE+: 48
  • 10GE/GE SFP+: 6
  • Console(RJ45): 1
  • Backplane(Gbps): 216
  • Forwarding rate (Mpps with 64 bytes): 162
  • Power consumption:
    • no-load: < 25W
    • full-load: < 48W(without PoE)
  • Power supply:
    • AC: 100V-240V, 450W
    • DC: 36-72V, 800W
  • Total output BTU (1000BTU/H=293W): 1535.84 AC, 2730.38 DC
  • Fan number: 2
  • Noise 25C(dBA): 45
  • MTBF(H): >200,000
  • Forwarding mode: Store-forward
  • Flash (MB): 16
  • DRAM (MB): 512
  • MAC: 32K
  • Buffer size(MB): 1.5
  • Interface vlan: 64
  • Routing table: 512
  • Jumbo frame: 9k
  • Features:
    • VLAN: 4K Active VLAN, QinQ and Selective QinQ, GVRP, Private VLAN, Voice VLAN
    • Spanning Tree:
      • 802.1D (STP), 802.1W (RSTP) and 802.1S (MSTP)
      • BPDU guard, root guard and loopback guard
    • Multicast: IGMP v1/v2/v3, IGMP Snooping, IGMP Fast Leave, MVR, IGMP filter
    • IP:
      • Static route
      • IPv4/v6 dual stack
    • IPV6:
      • ICMPv6, DHCPv6, ACLv6 and Ipv6 Telnet
      • IPv6 neighbor discovery, Path MTU discovery
      • MLD V1, MLD snooping IPv6 Static Routing, RIPng, OSPFv3
      • Manual tunnel, ISATAP tunnel, 6 to 4 tunnel
    • Certification: CE, FCC, ROHS
    • QoS:CAR, HQoS, MAC/IP/TCP/UDP/ VLAN/COS/DSCP/TOS based QoS, 802.1P/DSCP priority re- labeling, SP, WRR, and SP+WRR, Tail-Drop, WRED, flow monitoring and traffic shaping
    • Security:
      • Port isolation, Port security, and IP+MAC+port binding, MAC sticky
      • DHCP Snooping and option 82, DAI and IP source guard, PPPoE+
      • IEEE 802.1x, Radius and BDTacacs+
      • L2/L3/L4 ACL flow identification and filtrationAnti-attack from DDoS, TCPs SYN Flood, UDP Flood, etc. Broadcast/multicast/unknown unicast storm-control
      • MD5, SHA-256, RSA-1024, AES256, etc.
    • DHCP:
      • DHCP server/relay/client
      • DHCP snooping/option82
    • Reliability:
      • Static/LACP link aggregation, Interface backup
      • EAPS and ERPS
      • ISSU uninterrupted system upgrade
      • BVSS, ups to 16-units per stack
      • VRRP
      • UDLD
    • Management:
      • Console, Telnet, SSH v1/2, HTTP, HTTPS, SNMP v1/v2/v3, RMON
      • TFTP, FTP, SFTP
      • NTP
      • ZTP
      • SPAN, RSPAN
      • Dying gasp
    • Environment:
      • Operating temperature/ humidity: 0C -50C,10%-90% non-condensing
      • Storage temperature/humidity: -20C -70C, 5%-95% non-condensing
    • Accessories: Power cord, rackmount kits, console cable
  • Chassis:
    • Dimensions (WxDxH)(mm): 440x280x44
    • Weight (KG)(empty): 5.2
  • Package:
    • Dimensions (WxDxH)(mm): 576x448x94
    • Weight(KG): 6.1
