Specifications

• Mfr Part Number: S2510-C
• Interface: 8 GE TX ports, 2 100/1000M SFP ports
• Console: 1 RJ45 port, 1 RST button
• Switching Capacity: 20 Gbps
• Forwarding rate: 15 Mpps
• Power consumption:
  • no-load: < 3W
  • full-load: 10W
• Power supply: 15w
• Total output BTU (1000BTU/H=293W): 51.19
• Fan number: no
• Noise 25C(dBA): 0
• MTBF(H): >50,000
• Forwarding mode: Store-forward
• Flash (MB): 16
• DRAM (MB): 128
• MAC: 8K
• Buffer size(MB): 41
• Jumbo frame: 9k
• Total SVI: 10
• Features:
  • VLAN: 4K Active VLAN, QinQ and Selective QinQ, GVRP, Private VLAN, Voice VLAN
  • Spanning Tree:
    • 802.1D (STP), 802.1W (RSTP) and 802.1S (MSTP)
    • BPDU guard, root guard and loopback guard
  • Multicast: IGMP v1/v2/v3, IGMP Snooping, IGMP Fast Leave, MVR, IGMP filter
  • IP:
    • Static route, RIP, OSPF
    • 512 routing table
    • IPv4/v6 dual stack
    • DHCP Server/Client/Relay
  • QoS:
    • CAR, HQoS, MAC/IP/TCP/UDP/ VLAN/COS/DSCP/TOS based
    • QoS, 802.1P/DSCP priority re- labeling, SP, WRR, and SP+WRR
    • Tail-Drop, WRED, flow monitoring and traffic shaping
  • Security:
    • Port isolation, Port security, and IP+MAC+port binding, MAC sticky DHCP Snooping and option 82, DAI and IP source guard, PPPoE+
    • IEEE 802.1x, Radius and BDTacacs+
    • L2/L3/L4 ACL flow identification and filtrationAnti-attack from DDoS, TCPs SYN Flood, UDP Flood, etc.
    • Broadcast/multicast/unknown unicast storm-control
    • MD5, SHA-256, RSA-1024, AES256, etc.
  • DHCP:
    • DHCP server/relay/client
    • DHCP snooping/option82
  • Reliability:
    • Static/LACP link aggregation, Interface backup
    • EAPS and ERPS
    • ISSU
  • Management:
    • Console, Telnet, SSH v1/2, HTTP, HTTPS SNMP v1/v2/v3, RMON
    • TFTP, FTP, SFTP
    • NTP
    • ZTP(Zero Touch Provisioning)
    • SPAN, RSPAN
  • Accessories: Power cord, rackmount kits, console cable, anti-slipping pad
  • Environment:
    • Operating temperature/ humidity: -10C-50C, 10%-90% non-condensing
    • Storage temperature/humidity: -20C-70C, 5%-90% non-condensing
  • Certification: CE, FCC, ROHS
• Chassis:
  • Dimensions (WxDxH)(mm): 280x180x44
  • Weight (KG)(empty): 1.55
• Package:
  • Dimensions (WxDxH)(mm): 346x289x92
  • Weight(KG): 2.55
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country. All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.
